ü Sub Chassis: ISMC-E250JR-203x76****(JSPL) ISI AND ISO 9001-2008
ü Bottom Support : ISMC-E250JR 152X76**** (APL) ISI AND ISO 9001-2008, 22 to 25 support
ü Flooring : 5.5 mm Essar 52 steel sheets double side 360Mpa,UTS-440-550Mpa,EL-30% with IS 5986 TC Material .
ü Side door : TATA CRC :2.2 mm 66 steel sheet double side 360Mpa,UTS-440-550Mpa,EL-26% with IS 5986 TC Material.
ü Complete Finolex 5 mm wiring ARAI Approved
ü Rear door: TATA :2.5mm 66 steel sheet with IS 5986 TC Material
ü Beck side heavy duty crane safety fix guard and side safety guard
ü Duly painted with 1 coat of eproxy base zinc chrome primer and two coats of color of your choice
ü Rear Side in Bottom iron lattices and making ladder in centre
ü U section bolt and side plating 12mm
ü Welding : MIG/MAG Welding with Argon+CO2 Shield
ü Complete pin lock system in two side door
ü LED side lights & Elegant 3M radium decoration ARIA Approved R T O Norms
ü Rear side safety grill
