ü Fully Furnish Jodhpur Style cabin with TATA CRC steel 18 Guage sheets360 Mpa.UTS-440-550Mpa,EL26%
ü Sub Chassis: Hollow Tubes 205X110X6 mm *****(APL) ISI AND ISO9001-2008
ü Running Bottom Side: Hollow Tubes 98X65X6mm *****(APL) ISI AND ISO 9001-2008 : - 18 to 20
ü Vertical Side Support: Hollow Tubes 70X70X6mm *****(APL) ISI AND ISO 9001-2008: -18 to 20
ü Horizontal Side Support = Hollow Tubes 82X48X5mm **** (APL) ISIAND ISO 9001-2008
ü 50mm Tharmocol for cooling Temperature
ü Floor: 4mm plane Essar 52 steel sheets 360Mpa,UTS-440-550Mpa,EL26%
ü Side wall : 2.2mm Essar 52 ST 7 Grade 360Mpa,UTS-440-550Mpa,EL26%
ü U section bolt and side Platin 0
ü Base zinc chrome Duly painted with 1 coat of epoxy primer and two coats of color of Your choice
ü Welding : MIG/MAG Welding with Argon+CO2 Shield
ü LED side lights & Elegant radium decoration ARIA Approved R T O Norms
