About SHREE KANAIYA DUMPER


Title :

TRAILER

Description :


ü Size:-length: 7924.8mm, Height: 1981.2mm, Width: 2438.4mm

ü Sub chassis,  402x198x60 kg/m Steel E250 BR ISI2062:2011 ISO 1277

I-Beams with Welded cross member

ü Tip Chassis Size:90x90x6mm*****(APL) ISI AND ISO 9001-2008

ü 2 landing lagscapacity 62 tons

ü Floor:  6mm -360Mpa, UTS-440-550Mpa,EL-22%,

ü Flooring support :78x78x5mm*****(APL) ISI AND ISO 9001-2008 ( 21 to 24 support )

ü Walls: 3.9mm 360Mpa,UTS-440-550Mpa,EL-22%,

ü Vertical Sidesupport 355x72x6mm*****(APL) ISI AND ISO 9001-2008:- 8 Support

ü Side hook/side safetyguard, Chassis & Body balance system

ü Welding  : MIG/MAG Welding with Argon+CO2 Shield

ü 2 line air brakesystem with air tank, emergency relay valve, brake chamber and mechanical slackadjuster

ü 24 volt electricalsystem.  pin electrical connector.Parking, brake and indicator lights, Rear marker and side reflector.

ü Side under runprotection ( includes)

ü Duly painted with1 coat of aproxy base zinc  chrome  primer and two coats of color of your choice

ü With 8 TATA DiskDisposal

ü Cabin Renovation

ü New cushion andsit with 40 density

ü 3 pipe Air horn (HQ) 24v. multi melody composer
